Page 17
B1 B2
HWAM Monet HWAM Monet H
9
4
11
6
6
2
2
10
1
7
11
10
1
5
5
7
4
9
1. Side plates
2. Smoke Shelf
3. Bottom plates
4. Front plate
5. Back plate
2
5
1
1
3
3
4
Exploded view of the Skamol re-
fractory plates. Skamol is a very
heat resistant and highly insulat-
ing material made of processed
vermiculite. This material is ca-
pable of service temperatures up
to 1150 C (2101 F) It is however
somewhat fragile. Care should be
used when handling these pieces
and when fueling the stove.
