HWAM Monet - Automatic Air Control System Diagram

Page 28
12
3
2
1
346 4
4
5
4
1
276
10°
Automatic Air Control Parts and Assembly Diagram
1. Self-adhesive gaskets fixed to the stove
body.
2. 6 mm diameter washer to be placed
between stove body and automatic
system.
3. Slide gate assembly
4. 6 mm screws
5. Sensor system
6. Aluminium plate within the “Slide gate
assembly”
