c. The LCD display scroll will stop at the menu item for the auto close timer setting
[Ct __]. This is the first item in the User Menu.
d. To access the more detailed Installer Menu, the system must first be in the User Menu,
and then simultaneously press the Reset button and the Open button. The LCD will
change to display the UL usage class menu item [uC __] This is the first item in the
Installer Menu.
4. Pressing the Program Menu button when the User or Installer Menu is not blinking will return the
system to the Run Mode.
Installation Configuration for Smart Touch Controller for HTG
Basic Configuration and Setting of the Usage Class
1. Turn on the power switch and observe that the LCD will first show the software version, and then
stop at a steady display within two seconds. If the display reads [uC 0] go to step 2. If the
operator has previously been configured, the Installer Menu must be accessed in order to reach
the system configuration menu items: see step 3(d) at the top of this page.
2. When turning on the power for a new machine, the LCD display directly enters the Installer Menu
at the [uC __] menu item, which is for selecting the user class as defined by UL. Select [uC 1] -
[uC 2] - [uC 3] or [uC 4] depending upon the use application. See the entrapment Protection
Section for UL usage class definitions.
3. Once the usage class is set, you may want to configure some other menu items before exiting the
Installer Menu. The table below contains some common installer configuration items typical for a
barrier arm gate.
4. When ready to exit the installer Menu. press the Program Menu button. The LCD display jumps
to the close timer [Ct__] setting in the User menu, which may now be set. Either press the
Program Menu button again to exit to normal run mode or set the close timer by the same
programming sequence described at the previous page.
5. Note that the Installer menu cannot be exited by any means until the selection for the UL
usage class [uC __] has been entered.
