Installation and Maintenance Manual
22
Smart Touch Controller Installer Menu Functions
The Installer Menu can be accessed only by entering the User Menu first, and then by pressing the
Reset button and the Open button simultaneously.
The following table is the menu options for the HTG 320 Barrier Arm gate. Note that this menu adds
several items not used in our other gate operators. The most useful additions are several optional
control functions for the Reset Loop Detector, which is the loop directly under the barrier arm. Note:
I18 [Cr__] Controls whether the reset loop stops only or reverses for a tailgating vehicle.
I19 [Cb__] Allows bi-directional use by disabling the free exit loop when a vehicle enters.
I20 [CP__] Adds an open input counting function that allows the arm to stay open until a 2
nd
car exits.
This is useful to not trap the 2
nd
vehicle if the open input has some kind of anti-passback function.
I21 [Eb__] Allows the free exit loop to generate a close command when cleared.
Installer Menu Options Default Description
I1
[uC 0] Set UL Usage Class
0
0 = Gate disabled, Set Class 1 through 4 use
I2
[Fd 0] Load Factory Defaults 0 0 = User Settings, 1 = Load defaults (resets entire menu)
I3
[dg 0] Set Master/Slave type 0 0 = Solo operator, 1 = Slave unit, 2 = Master unit
I4
[Ch 0] Set AC Charger or Solar
0
0 = DC + AC charger, 1 = DC + Solar charger
I5
[Fo 0] Enable Fire Dept. Open 0 0 = input disabled, 1 = enabled
I6
[oC 0] Enable Emergency close 0 0 = input disabled, 1 = enabled
I7
[SE 3] Inherent Sensor sensitivity 3 1 = Maximum sensitivity, 9 = Lowest sensitivity
I8
[SS 0] Inherent Sensor function
0
1 = stop only (note, functions in usage class 4 only)
I9
[LC 0] Leaf delay Close
0
0 = none (1-7) ½ second steps (Master/Slave only)
I10
[Lo 0] Leaf delay Open
0
0 = none (1-7) ½ second steps (Master/Slave only)
I11
[rt 0] Maximum run timer 0 0 = 60 Seconds max run, 1 = 300 Seconds max run
I12
[EC 0] PEC reverse to open 0 0 = Close eye stops only, 1 = 2 sec reverse to open
I13
[PC 0] Set PEC output – NO/NC 0 0 = Normally Open PE output, 1 = N.C. (Supervised mode)
I14
[gC 0] Set Edge input – NO/NC 0 0 = Normally Open Edge output, 1 = Normally Closed
I15
[tC 1] Time clock/ Interlock input 1 0 = select Time Clock, 1 = select Open Interlock
I16
[or 1] OOLD detector function 1 0 = pause closing only, 1 = enable reversing to open
I17
[ir 1] IOLD detector function 1 0 = pause closing only, 1 = enable reversing to open
I18
[Cr 1] RLD -Reset detector function 1 0 = Reopen if tripped while closing, 1 = Pause only
I19
[Cb 0] RLD -Reset detector function 0 0 = One way, 1 = Bi-directional - disables ELD if tripped first
I20
[CP 0] RLD -Reset detector function 0 0 = Std. Close, 1 = Count opens & closes after equal reset
I21
[Eb 0] ELD –Exit detector function 0 0 = Off, 1 = Enable ELD back off auto close feature
I22
[r1 0] User relay 1 option 1 0 = disabled, 1 – 19 = see relay output options page 26
I23
[r2 0] User relay 2 option 6 0 = disabled, 1 – 19 = see relay output options page 26
I24
[r3 0] User relay 3 option 1 0 = disabled, 1 – 19 = see relay output options page 26
I25
[tL 0] Gate Open alert
2
0 = 0 sec, 1= 15s, 2= 45s, 3= 75s, 4= 105s, 5= 135s
I26
[Lt 0] Loitering alert
3
0 = 0 sec, 1= 15s, 2= 45s, 3= 75s, 4= 105s, 5= 135s
I27
[ELd0] Test factory ELD 0 0=Run, 1=show freq, 2=show call level 0-7, 3= set Freq 1-4
I28
[iLd0] Test factory IOLD 0 0=Run, 1=show freq, 2=show call level 0-7, 3= set Freq 1-4
I29
[oLd0] Test factory OOLD 0 0=Run, 1=show freq, 2=show call level 0-7, 3= set Freq 1-4
I30
[rLd0] Test factory RLD 0 0=Run, 1=show freq, 2=show call level 0-7, 3= set Freq 1-4
These Notes Refer to the Menu Above:
I1 This setting must be configured or the gate cannot function and menu will not exit.
I4 This setting appears only if the factory has provided a DC powered gate operator
I8 IES stop only setting [SS __] does not appear unless set as a class 4 operator
I9-10 These settings appear only if the Installer Menu is set for Master / Slave function
I25-26 These settings appear only if the Installer Menu has set relays r1-r3 for these alerts
