ANALOGUE MODULE SA-10 - ELECTRICAL CONNECTIONS See Page 66
Communication - From Controller or other module via a 2 core screened
cable connected to TB1. Refer to Page 9.
Power Supply - Selectable 110V or 230V AC +10%/-15%, 50Hz or 60Hz,
12VA is connected to TB4. Voltage selector SW4 must be set
to the correct voltage.
Analogue Outputs - Are connected to the +ve -ve and shield terminals of TB2 for
each point starting at Point 1 and leaving no gaps in the
programmed range.
RELAY MODULE SR-10 - ELECTRICAL CONNECTIONS See Page 63
Communication - From Controller or other module via a 2 core screened
cable connected to TB1. Refer to Page 9.
Power Supply - Selectable 110V or 230V AC +10/-15%, 50Hz or 60Hz, 12VA
is connected to TB4. Voltage selector SW4 must be set to the
correct voltage.
Relay Outputs - One Relay Module provides two relays for each point. If 4
relays are required for a point then two Relay Modules must be
used.
Relays are connected at TB2 for each point starting at Point 1
and leaving no gaps in the programmed ranged
MODULE IDENTIFICATION INSTRUCTIONS
Each Module (other than the Controller) must have an individual address number. This is set
on Switch (SW1) which is located on the upper left hand side of each Module.
The switch (SW1) on the Multiplexor must always be set to 1, with other Modules numbered
sequentially with no gaps in the sequence.
The total number of Modules connected to the Controller must be entered in Pr.51
NB - No two Module switches should be set to the same position.
