Appendix 2
Ref: REFLEX/SCANFLEX MANUAL
EDITION 1: JULY ’97 61
SCANFLEX MULTIPLEXOR SM-10
SPECIFICATION
Enclosure : IP65 Polycarbonate
Dimensions : 330H x 230W x 85D (mm)
Weight : 1.75Kg
Power Supply : 110/230V a.c. selectable 50/60Hz 12VA
Supply Variation : +10% -15%
Fuse Rating : 250mA slow-blow
Ambient Temperature : -40
o
C to +70
o
C
Relay : 10 off DPST, rated to switch the transducer and
temperature probe signals.
Indication : 1 off red l.e.d. to indicate power on
10 off red l.e.d's to indicate energisation state of relays
1 off green l.e.d. to indicate communications with
controller
Switches : 1 off module number selector
2 off relay test
Connections : Two part screw terminal connectors
