Appendix 4
Ref: REFLEX/SCANFLEX MANUAL
EDITION 1: JULY ’97 71
REFLEX PARAMETER SETTINGS
Pr Description Factory
Default
User Eng Pr Description Factory
Default
User Eng
Basic Set-up
Scanner Control
1 Single or Multi Point 1 49 Point Data Reset '===='
2 Transducer Type 1 50 Point Data Copy Over 0
3 Application/Units 2 51 Number of Modules 1
4 Empty Distance 30.00 52 Max. Time Per Point 15
5 Operational Span 30.00 53 Manual Scan Select 0
6 Blanking Distance 1.00
7 Rate of Change 1.00
Relays
Communications
8 Relay 1 Designation 0 62 Serial Comms. Enable 1
9 Relay 1 Set 0.00 63 Station Number 0
10 Relay 1 Reset 0.00
11 Relay 2 Designation 0
12 Relay 2 Set 0.00
Echo Detection
13 Relay 2 Reset 0.00 65 Maximum Gain 80.0
14 Relay 3 Designation 0 66 Gain Restriction 2
15 Relay 3 Set 0.00 68 Echo Selection 1
16 Relay 3 Reset 0.00 69 Echo Velocity 344.1
17 Relay 4 Designation 0
18 Relay 4 Set 0.00
19 Relay 4 Reset 0.00
Miscellaneous
20 Relay 5 Designation 0 70 Parameter Display 0
21 Relay 5 Set 0.00 71 Correction Value 0.00
22 Relay 5 Reset 0.00 72 Decimal Point 2
Failsafe 73 Software Revision No.
S/WAR
E
23 Failsafe R1 3 74 Reset Counter 0
24 Failsafe R2 3
25 Failsafe R3 3
26 Failsafe R4 3
Test Parameters
27 Failsafe R5 3 75 Digitial Output Set 0
28 Failsafe Analogue 3 76 Hardware Test '===='
29 Failsafe Time Delay 600 77 Transmitter Test '===='
Analogue 78 Simulation '===='
30 Analogue Output 1
32 Analogue Datum 0.00
Filter Settings
33 Analogue Span 100.0 80 Filter One
34 Analogue Test 0 81 Filter Two
Temperature
37 Probe Enable 1
Number Store
38 Temp. Compensation 20°C 95 Serial Number Store Ser.No
39 Probe Test 0.00 96 Security Code Store 15.02
Volume Conversion
40 Vessel Shape 0
Resets
41 Dimension H 0.00 97 Relay Totaliser Reset '===='
42 Dimension L 0.00 99 Total System Reset '===='
43 Display Conversion 1
44 Volume Linearisation '====='
