Appendix 3
Ref: REFLEX/SCANFLEX MANUAL
EDITION 1: JULY ’97 70
Required Values
Point
Number
'A'
% Level
'A'
Key in Values
'B'
% Volume
'B'
Key in Values
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
0
10
20
30
40
50
60
70
80
90
100
110
255
255
255
255
0
10
20
30
40
50
60
70
80
90
100
110
255
255
255
255
0.0
3.3
16.1
27.3
37.5
48.5
59.5
70.5
80.0
89.5
100.0
Not Used
Not Used
Not Used
Not Used
Not Used
0
33
161
273
375
485
595
705
800
895
1000
Not Used
Not Used
Not Used
Not Used
Not Used
NOTE: 1. Points 13 to 16 not used - leave at factory default value.
2. 'A' values must be whole numbers, no decimals allowed.
3. 'B' values must be entered as the 'key-in' value, the
decimal will be automatically allocated.
Now continue programming the instrument as follows:
Programme the instrument exactly as Example 2 on Page 35, except:
Change Pr.40 from 1 to 8, which denotes vessel linearisation
Go to Pr.44 and proceed as follows:
Press Pr.44 to display Pr.44:
Press 'DSP'
Press 'ENT' to show 'A1' and the value held in 'A1' (default = 255)
Key in the value 'O' from Table 1 and press 'ENT' to show
.0 again.
Press '▲' to show 'A2' and the value held in '2' (default = 255)
Key in the value 10 from Table 1 and press 'ENT'
Continue for all points which you need to use (up to 'A16)'
Any points not used must be left at the default of 255
Press '▼' several times to return to 'A1'
Press # to show 'B1' and the value held in 'B1' (default = .0)
Key in the value '0' from Table 1 and press 'ENT' to show
.0 again.
Press '▲' to show 'B2' and the value held in 'B2' (default = .0)
Key in the value '33' from Table 1 (accepted as 3.3)
Continue for all points which you need to use (up to B16)
Any points not used must be left at the default of .0
Press 'TEST' then 'DSP' to move the cursor under Pr.44
Leave the linearisation part of the programme by displaying
any other parameter, or go into 'RUN' mode.
