12. Technical specications
Input data
Measuring range 0 .. +100 °C (+32 .. 212 °F)*
Output data
Accuracy (display, analogue output) ≤ ± 1.0 °C (≤ ± 2.0°F)
Repeatability ≤ ± 0.25 % FS
Temperature drift (ambient) ≤ ± 0.03 % FS / °C max. zero point
≤ ± 0.03 % FS / °C max. range
Analogue output (optional)
Signal selectable:
4 .. 20 mA ohmic res. max. 400 W
0 ..10 V ohmic res. min. 2 kW
corresp. in each case to 0 .. +100 °C
Switching outputs
Type 4 relays with change-over contacts
in 2 groups
(common supply of
each group connected)
Switching voltage
0.1 .. 250 V A
C, 12 ..32 V DC
Switching current 0.009 .. 2 A per output
Switching capacity 400 VA, 50 W
(for inductive load, use varistors)
Switching cycles > 20 million at minimum load
> 1 million at maximum load
Ambient conditions
Ambient temperature range -25 .. +60 °C
Storage temperature range -40 .. +80 °C
mark EN 61000-6-1 / 2 / 3 / 4
Vibration resistance to ≤ 5 g
DIN EN 60068-2-6 (0 .. 500 Hz)
Shock resistance to ≤ 10 g
DIN EN 60068-2-29 (1 ms)
Protection class to DIN 40050 IP 65
Other data
Supply voltage 22 .. 32 V DC
Current consumption approx. 200 mA
Residual ripple of supply voltage ≤ 10 %
Display 4-digit, LED, 7 segment, red,
height of digits 13 mm
Weight approx. 800 g
Note: Reverse polarity protection of the supply voltage, excess voltage,
override, short circuit protection are provided.
* The uid temperature range of the connected temperature sensor can
restrict the display range of the ETS 1700.
FS (Full Scale) = relative to the complete measuring range
Technical specications accessories:
Temperature probe TFP 100
Fluid temperature range -40 .. +125 °C (-40 .. +257 °F)
Electrical connection Male Binder series 714 M18, 4 pole
M12x1, 4 pole
Parts in contact with uid Brass
mark EN 61000-6-1 / 2 / 3 / 4
Supply voltage 9 .. 35 V DC
Protective sleeve for tank-mounting the TFP 100
Pressure resistance 10 bar
Parts in contact with uid CuZn39Pb3 (brass), nickel-plated
