15. Dimensions
13. Model code
ETS 1 7 0 X - 100 - 000
Type of sensor
0 = for PT 100 sensors
(Sensor TFP 100 must be ordered separately,
see below)
Display
1 = 4-digit °C
2 = 4-digit °F
Measuring range
100 = 0 .. 100 °C / 32 .. 212 °F
Modication number
000 = standard (determined by manufacturer)
14. Accessories
14.1. ACCESSORIES SUPPLIED WITH THE UNIT
 PG 11 cable glands
 4 mounting screws M5 x 20 mm
 5-pole Binder connector, series 681
 3 m connection line for TFP 100 (LIYCY 4x0.25 mm²)
14.2. OTHER ACCESSORIES
(must be ordered separately)
 Temperature sensor TFP 104 (version of the TFP 100 with 4-pole connection
Binder series 714 M18, including connector ZBE03)
 Temperature sensor TFP 106 (version of the TFP 100 with 4-pole connection
M12x1, without connector)
 Safety sleeve for tank mounting
 Mounting kit (4 vibration mounts, 4 screws M5 x 6 mm)
cable gland PG11
female connector
Binder series 681 -5p
countersunk to DIN74-KM5
