FAM 15/30/50/70 Model Code
HYDAC Filter Systems GmbH
en
Page 63 / 68
BEWA FAM15-70Siem 3099574e en 2009-10-08.doc 2008-10-06
Model Code
FAM - 70 - M - 1 - A/1900 - 060 - DM - 02 - S - z - 1
Product
FAM = FluidAqua Mobil
Filter Size
15 = 17 l/min
30 = 36 l/min
50 = 56 l/min
70 = 76 l/min
Operating fluid
M = Mineral oil
I = Insulating oil
X = HFD Fluids
B = Rapidly biodegradable fluid
Mechanical type
1 = stationary
2 = mobile (with rollers and hose holder)
Voltage / Frequency / Power supply
A = 400 V, 50 Hz, 3 Ph+PE
B = 415 V, 50 Hz, 3 Ph+PE
C = 200 V, 50 Hz, 3 Ph+PE
D = 200 V, 60 Hz, 3 Ph+PE
E = 220 V, 60 Hz, 3 Ph+PE
F = 230 V, 60 Hz, 3 Ph+PE
G = 380 V, 60 Hz, 3 Ph+PE
H = 440 V, 60 Hz, 3 Ph+PE
I = 500 V, 50 Hz, 3 Ph+PE
K = 480 V, 60 Hz, 3 Ph+PE
L = 220 V, 50 Hz, 3 Ph+PE
N = 575 V, 60 Hz, 3 Ph+PE
O = 460 V, 60 Hz, 3 Ph+PE
X = other voltage
Filter size fluid filter
15 = OLF 15, 1x N15DM0xx
30 = OLF 30, 2X N15DM0xx
45 = OLF 45, 3X N15DM0xx
60 = OLF 60, 4X N15DM0xx
1300 = OFU 1300, 1x 1300RxxxBN4HC/-KB
2600 = OFU 2600, 1x 2600RxxxBN4HC/-KB
z = without Filter housing
others on request
Filter material of element
DM = Dimicron
®
BN = Betamicron
®
z = without filter element
Filtration rating
02 = 2 µm (DM)
03 = 3 µm (BN)
05 = 5 µm (DM/BN)
10 = 10 µm (DM/BN)
20 = 20 µm (DM/BN)
30 = 30 µm (DM)
z = without filter element
Type of vacuum pump
S = Standard - Water Ring Vacuum Pump
SW = Automatic water feed
D = Rotary vane vacuum pump
Instrumentation
z = Without
A = AquaSensor (AS)
C = ContaminationSensor (CS)
AC = AquaSensor + ContaminationSensor
Modification number
1
Supplementary details
Without details = standard
