HydraMaster Boxxer 421 - Dash Assembly Parts List

HydraMaster Corporation
Page 11-12: Machine Assemblies and Parts List
Boxxer 421
Item Part Number Description Qty
Dash Assembly Parts List
1 000-100-120 Panel, Dash - Boxxer 421 1
2 000-100-123 Panel, Perforated Grill - Boxxer 421 1
3 000-157-008 Switch, Ignition 1
4 000-074-018 Meter, Rectangular w/o Bezel 1
5 000-061-056 Knob, Temperature Adjustment 1
6 000-025-011 Cable, Choke (5 Foot) 1
7 000-052-272 Cup, Gravity Feed Oil Blower Lubrication Port 1
8 000-025-020 Cable, Throttle Kohler 1
9 000-074-016 Gauge, Temperature 1
10 000-074-017 Guage, 0-30" Hg Vac. 2 1/2" Hydramaster Face 1
11 000-074-007 Gauge, Pressure (0-1500 PSI) 1
12 000-052-088 Elbow, 1/4" FPT x FPT 1
13 000-157-040 Switch, 20 AMP Rocker 4
14 000-169-160 Valve, Chemical Metering 1
15 000-074-030 Meter, Chemical Flow Raw 1
16 000-052-084 Elbow, 1/8" NPT Street 2
17 000-052-099 Insert, #26 (1/8" NPT x 3/8" Barb) 3
18 000-169-0171 Valve, 3-Way Ball O-Ring Style 1
19 000-149-560 Thermostat, Potentiometer Use w/ RTD 1
20 000-052-096 Insert, #F23 (1/8" FPT x 3/16" Barb) 1
21 000-052-069 Nipple, 1/8" NPT Hex 3
22 000-052-531 Elbow, 1/8" NPT x 1/4" SAE 2
23 000-174-001 Washer, #10 Flat 14
24 000-094-034 Nut, #10-24UNC Nylock 4
25 000-094-098 Nut, 7/16"-24UNF - 2 Way Metering Valve 1
26 000-052-527 Nipple, 1/4" SAE x 1/4" NPT 1
27 000-094-070 Nut, 5mm Nylock 6
28 000-052-089 Elbow, 1/8" NPT Female 2
29 000-174-014 Washer, #10 Lock 2
30 000-143-328 Screw, #10-32UNF x 1/2" Lg. Phillips Head 2
