Page 8-1: Electrical System
Boxxer 421
Electrical System
T
he Boxxer electrical system, in keeping with the entire machine concept, has
been kept to a minimum so as to keep any necessary troubleshooting as easy as
possible.
The entire electrical system operates on 12 volts DC which is provided by a battery.
Battery levels are sustained by a 16 amp alternator inside the engine.
NOTE: When a new battery is installed, check that it is properly charged before
installation or damage to the charging regulator may occur.
The orange wire going from the engine starter solenoid to terminal #5 on the ignition
switch is a fusible link and provides protection to the electrical system in case of
failure.
Ignition Switch:
Terminal No. Wire Color Function
1 Not Used
2 White To Carburetor Solenoid (when used)
3 Black To Stop Switch Terminal on Engine
4 Yellow To Solenoid (tab terminal)
5 Orange To Battery (battery terminal on solenoid)
6 Red To Regulator / Rectifier
Switch Position Continuity
1 Off 1 + 3 + 6
2 Run 2 + 5 + 6
3 Start 2 + 4 + 5
