HydraMaster Boxxer 421 - Hose Assemblies

HydraMaster Corporation
Page 11-54: Machine Assemblies and Parts List
Boxxer 421
Boxxer 421 Hose Assemblies
Hose Hose
Part No. Description
From To Qty
068-018
1/2" Rubber Bypass Valve (169-081) Poly Water Box Tank (159-105) 48 in
068-030
5/32" Vac. 0-30” Hg Vac. Gauge (074-017) Blower Collector Box (013-051) 34 in
Engine Intake Diverter Check Valve (169-156) 48 in
Diverter Check Valve (169-156)
3/16” Plastic Vac Tee (052-155) 24 in
Gravity Feed Oil Cup (052-272) Blower Collector Box (013-051) 50 in
Blower Collector Box (013-051) Diverter Check Valve (169-156) 9 in
Diverter Check Valve (169-156)
3/16” Plastic Vac Tee (052-155) 11/2 in
3/16” Plastic Vac Tee (052-155) 3/16” Plastic Vac Tee (052-155) 13/4 in
3/16” Plastic Vac Tee (052-155) Upr. Primary Vac. Solenoid Valve 24 in
(169-070)
3/16” Plastic Vac Tee (052-155) Upr. Primary Vac. Solenoid Valve 52 in
(169-070)
Upr. Primary Vac. Solenoid Valve Air Cylinder Valve (169-169) 16 in
(169-070)
Upr. Primary Vac. Solenoid Valve Air Cylinder Valve (169-169) 8 in
(169-070)
068-085
3/8" HiTemp 12v Solenoid (169-082) 180°F Valve (169-011) 5 ft
on Recovery Tank
Chem. Pump (111-035) Chem. Meter. Valve (160-160) 2.5 ft
068-219 1/2" w/Inserts Engine Oil Drain Hose, 24 in
and Cap. Pump Oil Drain Hose,
2x Blower Oil Drain Hose
068-103
1/2" Blue Hard Water MagnaClean Poly Water Box (159-105) 58 in
(163-056)
068-326
3/8" Clr Chem. Jug Pick-up Chem. Meter. Valve (169-160) 5 ft
w/braid
Chem. Jug Return 3-way Chem. Valve (169-0171) 5 ft
