HydraMaster Boxxer 421 - Hose Assemblies (cont.)

Page 11-55: Machine Assemblies and Parts List
Boxxer 421
Boxxer 421 Hose Assemblies
Hose
Part No. Description
From To Qty
068-398 3" ID x 3 ply Blower Heat Ex. (038-053) Silencer (093-080) 6 in
Silicone
x 36"lg. Exhaust Turn Down Adapter Blower Heat Exchanger
1/4 in
(011-098) (038-053)
068-588 Throb HydraPump (111-042) Bypass Valve (169-081) 50
1/2 in
068-641
3/8" Teflon Bypass Valve (169-081) Blower Heat Exchanger 10 in
w/JIC ends (038-053)
068-642
3/8" Teflon Blower Heat Ex. (038-053) After-Burner (038-054) 191/2 in
w/JIC ends
068-643
3/8" Teflon Hi PSI Manifold (090-010) Hi PSI Manifold (OUT) 301/2 in
w/JIC ends (090-008)
068-644 3/8" Teflon After-Burner (038-054) Hi PSI Manifold (090-010) 491/2 in
w/JIC ends
068-645
3/16" Teflon Pressure Gauge, 3/8" Female Cross (052-113), 193/4 in
w/ JIC Ends 0-1500p (074-007) on Bypass Valve (169-081)
068-646 3/16" Teflon Chem. Pump (111-035) 3-Way Chemical Valve 291/4 in
w/ JIC Ends (169-0171)
068-647
3/16" Teflon Primary Orifice (180-004) Poly Water Box Tank 471/4 in
w/ JIC Ends (159-105)
068-648 3/16" Teflon Secondary Orifice (180-006) 12V, 1200 PSI Solenoid 611/4 in
w/ JIC Ends Valve (169-082)
068-649 3/4" Steam HydraPump (111-042) Poly Water Box Tank (159-105) 23 in
OUT
068-660
1/4 Fuel Carburetor Fuel Pump (111-008)
068-086 2” Rubber
3/8" Dump Valve (169-064) Bypass Valve (169-081) 18 in
