Page 11-17: Machine Assemblies and Parts List
Boxxer 421
1 000-159-105 Tank, Poly Water Box 1
2 000-041-237 Cover, Water Box 4" 1
3 000-052-155 Tee, 3/16" Plastic Vacuum Insert 1
4 000-157-031 Switch, Side Mount w/ Bulkhead Fitting 1
5 000-169-167 Valve, Mechanical Incoming Water - Water Box 1
6 000-143-314 Screw, #8 x 1/2" Lg. Pan Head 6
7 000-052-105 Insert, #68 (3/8" NPT x 1/2" Barb) 1
8 000-174-063 Washer, 1.5" O.D. x 1.073" I.D. x 0.075" Thk. 2
9 000-057-052 Gasket, 1" Garden Hose 1
10 000-005-007 Float, Water Box 1
11 000-143-336 Screw, #10-32UNF x 0.25" Lg. Pan Head Phillips 1
12 000-052-086 Elbow, 3/8" NPT Street 1
13 000-052-099 Insert, #26 (1/8" NPT x 3/8" Barb) 1
14 000-068-326 Hose, 3/8" Clear w/ Braid Solution 1
15 000-033-005 Clamp, Size #5 Hose 1
Item Part Number Description Qty
Water Box Assembly Parts List
