Page 11-19: Machine Assemblies and Parts List
Boxxer 421
Item Part Number Description Qty
Hydra Pump II Assembly Parts List
1 000-111-042 Pump, Hydra II Hi PSI 3.5 GPM 1
2 000-105-148 Plate, Hydra Pump II Clutch Mounting 1
3 000-036-008 Clutch, Electric Pump 1
4 000-106-003 Plug, 3/8" NPT Hex 1
5 000-106-004 Plug, 1/2" NPT Hex 1
6 000-052-086 Elbow, 3/8" NPT Street 2
7 000-052-087 Elbow, 1/2" NPT Street 1
8 000-143-141 Screw, 1/4"-20UNC x 1/2" Lg. Whiz Lock 4
9 000-052-547 Nipple, 1/2 NPT x 3/4 SAE 1
10 000-001-096 Adapter, Chemical Pump To Comet Pump 1
11 000-111-035 Assembly, Chemical Pump (Fig. 11-17) 1
12 000-052-085 Elbow, 1/4" NPT Street 1
13 000-052-099 Insert, #26 (1/8" NPT x 3/8" Barb) 1
14 000-052-128 Nipple, 3/8" NPT x 3/8" Male Propane 1
15 000-052-530 Nipple, 1/8" MNPT x 1/4 SAE 1
16 000-068-219 Hose, Spitfire Pump Drain 1
17 000-143-221 Screw, 6mm-1 x 14mm Lg. Hex Head 4
