HydraMaster Corporation
Page 11-30: Machine Assemblies and Parts List
Boxxer 421
Hi PSI Manifold Assembly Parts List
Item Part Number Description Qty
1 000-090-010 Manifold, Hi-PSI 1
2 000-180-006 Orifice, Set Screw 0.061" 1
3 000-180-004 Orifice, Set Screw 0.033" 1
4 000-052-423 Bushing, Modified Set Screw Orifice 2
5 000-049-016 Filter, 1/4" NPT Replacement “Y” 2
6 000-106-111 Plug, 1/2" NPT Allen 1
7 000-155-020 Spring, 0.540 O.D. x 0.041 Wire x 1.00 Lg. 2
8 000-106-008 Plug, 3/8" NPT Allen Head 1
9 000-052-082 Elbow, 1/4" NPT Street x 45° 2
10 000-052-064 Bushing, 1/2" NPT x 3/8" FPT 1
11 000-052-023 Tee, 3/8" NPT Male Street 2
12 000-052-528 Nipple, 3/8" M JIC x 3/8" NPT 2
13 000-052-527 Nipple, 1/4" SAE x 1/4" NPT 2
14 000-149-039 Sender, Temperature 1
15 000-149-027 Sensor, 285° Nason - 3/8" NPT 1
16 000-149-540 Sensor, RTD Compresion Fitting Style 1
17 000-052-061 Bushing, 3/8" NPT x 1/4" FPT 1
18 000-106-007 Plug, 1/4" NPT Allen Head 1
19 000-052-587 Compression, 3/16" x 1/4" NPT Thermocouple Fitting 1
20 000-052-086 Elbow, 3/8" NPT Street 1
21 000-052-083 Elbow, 3/8" NPT Street x 45° 1
