HydraMaster Boxxer 421 - 100 Gallon Universal Recovery Tank Assembly Parts List

Page 11-39: Machine Assemblies and Parts List
Boxxer 421
100 Gallon Universal Recovery Tank Assembly Parts List
Item Part Number Description Qty
1 000-159-129 Tank, 100 Gallon Universal Recovery - Weldment 1
2 Fig. 11-29 Assembly, Recovery Tank Cover - 100 Gallon 1
3 000-157-090 Float, Lever Switch 2
4 000-079-091 Kit, Dura-Flow APO - Production (Fig. 11-27) 1
5 000-105-336 Plate, Vacuum Port Cover - 100 Gallon Universal Recovery T 1
6 000-049-152 Filter, Recovery Tank Basket 1
7 000-049-153 Filter, Flat - Recovery Tank 1
8 000-012-002 Block, 6 Post Terminal 1
9 000-015-932 Bracket, Flat Filter Securing - Universal Recovery Tank 1
10 000-033-023 Clamp, 3/4" Nylon Hose 2
11 000-049-154 Deflector, Air - Univeral Recovery Tank 1
12 000-057-206 Gasket, Adapter - Universal Recovery Tank 2
13 000-140-023 Rivet, AB8-6A Aluminum Pop 6
14 000-143-126 Screw, #10-24UNC x 0.50" Lg. Hex Head 5
15 000-143-051 Screw, #8-32UNC x 0.75" Lg. Binder Head Phillips 2
16 000-094-059 Nut, #8-32UNF Nylock 2
17 000-086-008 Latch, Bungie 1
18 000-143-539 Screw, #6-32UNC x 0.50" Lg. Button Head Allen 2
19 000-094-063 Nut, #6-32UNC Nylock 2
20 000-174-019 Washer, 1/4" Lock 2
21 000-174-003 Washer, 1/4" Flat 18
22 000-106-019 Plug, 1-1/2" NPT 1
23 000-052-763 Nipple, 1-1/2" IPS Close s/s 1
24 000-169-022 Valve, 1-1/2" Full Port Ball 1
25 000-052-226 Insert,1-1/2" NPT x 1-1/2" Barb (Grey) 1
26 000-052-082 Elbow, 1/4" NPT Street x 45° 1
27 000-052-102 Insert, #46 (1/4" NPT x 3/8" Barb) 2
28 000-081-220 Label, Maintenance & Lubrication Schedule 1
29 000-143-333 Screw, 1/4"-20UNC x 0.50" Lg. Hex Head 2
30 000-001-131 Adapter, Tank To Ø2.5" Blower Hose - Universal Recovery T 1
