HydraMaster Corporation
Page 11-44: Machine Assemblies and Parts List
Boxxer 421
31 000-174-029 Washer, 3/8" Rubber Back 2
32 000-094-034 Nut, #10-24UNC Nylock 2
33 000-106-049 Plug, 1" NPT Allen Head 1
34 000-174-060 Washer, 1/4" Flat Rubber Backed 4
35 000-143-002 Screw, 1/4"-20UNC x 1.00" Lg. Hex Head 8
36 000-094-113 Nut, 1/4"-20UNC Neoprene Wellnut 4
37 000-174-036 Washer, #10 Flat Rubber Backed 2
38 000-174-001 Washer, #10 Flat 2
39 000-052-662 Nipple, 3/8" NPT x 1/4" M SAE 1
40 000-052-071 Nipple, 1/4" NPT Hex 1
41 000-052-088 Elbow, 1/4" FPT x FPT 1
42 000-094-009 Nut, 1/4"-20UNC Hex Nylock 4
43 000-052-727 Elbow, 1.5" x 1.5" NPT x 90° 1
70 Gallon Universal Recovery Tank For 85 RMT Assembly Parts List
Item Part Number Description Qty
