HydraMaster Boxxer 421 - Wand Assembly Parts List

HydraMaster Corporation
Page 12-2: Chemical Wand Parts
Boxxer 421
Wand Assembly Parts List
ITEM PART NO. DESCRIPTION QTY
1 061-007 Handle Grip 1
2 015-203 Bracket, Low Pressure Wand Valve Holder 1
3 167-018 Trigger, Wand Low PSI 1
4 052-082 Elbow, ¼” Brass 45 Street 1
5 052-072 Nipple, ¼ Brass Close 1
6 052-050 Quick Connect, 440 Male with Viton 1
7 169-074 Valve, High PSI Brass 1
8 052-152 Compression, ¼” Male HydraHoe Fitting 2
9 168-001 Tube, HydraHoe Solution ¼” OD s/s 1
10 061-024 Handle Kit, Wand – Pressure Guide (see below) 1
11 052-450 Elbow, For Jet Assembly Wands 1
12 076-004 Jet, #11004 ¼” VV s/s 1
Handle Assy (Item 10)
094-035 Nut, 5/16-18 s/s Nylock Half 2
143-012 Bolt, 5/16-18 x ¾” HHC s/s 2
061-006 Handle, Pressure Guide 1
