Smartec HSA 11
REQUIRED TOOLS
Miscellaneous Sockets
Ratchet, 3/8” 1/4” Deep
Flat Blade Screw Driver 1/4” 3/8” Deep
Phillips Screw Driver #2
Torque Wrench
Rubber or Neoprene Mallet
5/32” Hex Wrench
REQUIRED TORQUE VALUES
Item Description Torque Operation
7 Bolt, trunnion 200-250 in lbs
HSA magnet bolt
8 Screw, 1/4-20 X .75 BHCS 90-110 in lbs Bracket mounting screws
11 Screw, hex washer 1/4-20 X.75 90-110 in lbs Band clamp screws
14 Screw, 1/4-20 X .75 HF 50-80 in lbs HSA bracket screw
15 Screw, jackshaft 170-200 in lbs HSA jackshaft mounting screw
Table 4. Required Tools
Table 5. Required Torque Values
TOOLS AND TORQUE SPECIFICATIONS
