T2™ 15
TOOLS
As a general rule, use the low end of the torque spec on fasteners when
reassembling the unit.
TORQUES
REQUIRED TOOLS
Miscellaneous Sockets
Flat Blade Screw Driver (2) 1/2”-3/8” Adapter
Torque Wrench 1/2” Deep
Air Impact Wrench 7/16” Deep
Rubber or Neoprene Mallet 3/4” Deep
Breaker Bar 7/8” Deep
Side Cutters/Snips 9/16” Deep
Needle Nose Pliers T-40 Torx Head
Large External Snap Ring Pliers 10 mm
Small Internal Snap Ring Pliers
REQUIRED TORQUE VALUES
Item Description Torque Operation
8 HFHCS 1/4-20 x 1.25 105-155 in-lbs [11.8-17.5 Nm] Housing screw
13 Plug 9/16-18 (Metal) 180-240 in-lbs [20.3-27.1 Nm] Fill plug
22 Bolt, Hex Flange, 3/8-16, CS 525-700 in-lbs [59.3-79.1 Nm] Center section bolt
24 Check plug 280-400 in-lbs [31.6-45.2 Nm] Check plugs
25 Check plug 280-400 in-lbs [31.6-45.2 Nm] Check plugs
41 TWHCS 5/16-18 x 1 230-310 in-lbs [25.9-35.0 Nm] Trunnion arm screw
43 Screw, set 5/16-24 x 2.50 135-155 in-lbs [15.2-17.5 Nm] Control arm stud
49 Nut, hex 5/16-24 nylon insert 85-120 in-lbs [9.6-13.5 Nm] Friction Pack Nut
127 HFHCS 1/4-20 x 2.0 w/ patch 80-120 in-lbs [9.0-13.5 Nm] Brake yoke screw
128 HHCS 1/4-20 x 1 (patch) 80-120 in-lbs [9.0-13.5 Nm] Brake yoke screw
140 5/16 SAE, 5/32 tube 96-120 in-lbs [10.8-13.5 Nm] Expansion tank fi tting
144 Bolt, self-tapping 10-32 x 0.5 25-50 in-lbs [2.8-5.6 Nm] Expansion tank screw
152 Nut, Hex Lock 1/2-20 360-520 in-lbs [40.7-58.8 Nm] Fan Nut
153 HFHCS 1/4-20 x 0.75 50-80 in-lbs [5.7-9.0 Nm] Fan Screws
168 Lock Down Screw 135-155 in-lbs[15.3-17.5 Nm] RTN Arm
