Hydro-Gear T2 - T2 Transaxle Parts List

36 T2™
T2™ TRANSAXLE PARTS LIST
1 Housing, Main
2Cover, Side
7 Seal, Lip (included in Center Section Kit 202)
8 HFHCS 1/4-20 x 1.25
10 Gasket Material, Loctite 5900
11 Oil, 20W50
13 Plug
20 Center Section
22 Bolt, Hex Flange
23 Plate, Bypass
24 Check Plug Assembly
25 Check Plug/w Assembly
26 Bottom, Filter
27 Cover, Filter
28 Ring, Magnet
29 Defl ector
30 Seal, Lip (included in Center Section Kit 202)
31 Ring, Retaining (included in Center Section Kit 202)
32 Rod, Actuator
33 Ring, Retaining (included in Center Section Kit 202)
34 Arm, Bypass
35 Ring, Retaining (included in Center Section Kit 202)
40 Trunnion, Swashplate
41 TWHCS 5/16-18 x 1.00
42 Arm, Control
43 Screw, Set
44 Washer , Belleville
45 Washer, Plastic .32 x .80 x .21
46 Washer .34 x .88 x .06
47 Spacer .32 x .59 x .50
48 Spring, Helical Comp
49 Nut, Hex 5/16-24 nylon insert
61 Input Shaft
62 Bearing, Ball 15 x 35 x 11
63 Ring, Retaining (included in Center Section Kit 202)
64 Washer 1.23 x 1.56 x .04
65 Seal, Lip (included in Center Section Kit 202)
66 Ring, Retaining (included in Center Section Kit 202)
67 Spring, Helical
70 Block, Cylinder 8cc
71 Piston 8cc
72 Spring, Comp 8cc Piston
73 Washer, Piston seat
74 Bearing, Thrust 27 x 47 x 14
75 Block, Cylinder 10cc
76 Piston 10cc
77 Spring, Comp 10cc Piston
78 Washer, Piston Seat .47 OD
79 Bearing, Thrust Ball 30 x 52 x 13
80 Ring, Retaining .50 External Motor Shaft (part of 202)
81 Gear, 13T Pinion
82 Shaft, Motor
83 Washer .60 x 1.00 x .03
90 Gear 11T/48T
91 Gear, Jack Shaft 11T
92 Jack Shaft (Pin)
93 Washer .50 x 1.00 x .03
100 Ring, Retainer (included in Center Section Kit 202)
101 Gear, Bevel 12T Spline ID
102 Gear, Bevel 12T .50 ID
103 Axle .75 x 11.39 DD RH
104 Axle .75 x 16.99 DD LH
105 Bushing, Inboard
106 Bushing, Outboard
107 Gear 53T Bull
108 Pin, Differential
109 Ring, Retaining Internal Axle (part of 202)
110 Seal, Lip .75 x 1.125 x .25 TC (part of 202)
120 Puck, Brake
121 Rotor, Brake
122 Plate, Puck
123 RHCS 5/16-24
124 Yoke, Brake
125 Pin, Brake
126 Spacer
127 Screw 1/4-20 x 2.0
128 Screw 1/4-20 x 1.0
129 Spring
130 Arm, Brake
131 Washer
132 Nut, Castle 5/16-24 PL
133 Pin, Cotter
134 Spring, Brake arm
140 Tube 5/16 SAE 5/32
141 Hose
142 O-Ring .103 x .299 ID (part of 202)
143 Tank, Expansion
144 Bolt, Selp Tapping 10-32 x 1/2
145 Tube
146 Clip, Hairpin
147 Fastener, Ratchet (included in Center Section Kit 202)
150 Fan
151 Pulley
152 Nut
153 Washer
153 Screw 1/4-20 x 0.75
160 Arm, Control RTN
161 Arm, Neutral RTN
162 Arm, Scissor
163 Bushing, RTN Trunion
164 Washer, Plastic .68 x 1.00 x .03
165 Bushing
166 Spacer, Plastic
167 Spring
168 Lock Down Screw 5/16-24 x .94
169 Spacer
202 Center Section Kit
