Hydrovane HR07 - Technical Data HR04-HR07

2.0 Product Information
_________________________________________________________________________________________
8 CC1132751C
2.5 Technical Data HR04-HR07
Model Number HR04 HR05 HR07 HR07RS
PERFORMANCE DATA (50Hz)
F.A.D. litres/sec (cfm) @ 7 bar/102 psi
11.42 (24.20)
15.35 (32.52)
21.23 (45.00)
20.53 (42.50)
F.A.D. litres/sec (cfm) @ 10 bar/145 psi
9.50 (20.10)
12.75 (27.02)
17.34 (36.75)
17.37 (36.80)
PERFORMANCE DATA (60Hz)
F.A.D. litres/sec (cfm) @ 7 bar/102 psi
10.05 (21.30)
15.06 (31.90)
18.17 (38.50)
20.53 (42.50)
F.A.D. litres/sec (cfm) @ 10 bar/145 psi
8.35 (17.70)
10.34 (21.90)
14.21 (30.10)
17.37 (36.80)
PERFORMANCE
Power - kW (hp)
4.0 (5.5)
5.5 (7.5)
7.5 (10)
Noise Level - dBA
67
69
Starter Type
DOL (60Hz) and SD (50Hz)
Inverter
Drive Type
Direct
Operating Controls
Continuous Run, Automatic Stop/Start,
Reduced Energy Vent System
Variable
Rotation Speed - rev/min 50Hz (60Hz)
1450 (1760)
1100 *-2150 *
Ambient Temperature Range °C (°F) 0 to 45 (32 to 113)
0 to 40
(32 to 104)
Maximum Relative Humidity %
85 non-condensing
Air Discharge Temp - °C (°F) above ambient
<6 (43)
<8 (46)
<10 (50)
FACTORY SETTINGS
Nominal Pressure – bar (psi)
7.0 or 10.0 (102 or 145)
7.0 (102)
Minimum Pressure Valve – bar (psi)
5.5 to 6.0 (80 to 87)
Load/Cut-in Pressure – bar (psi)
6.5 or 9.5 (94 or 138)
7.0 (102)
Unload/Cut-out Pressure – bar (psi)
7.5 or 10.5 (109 or 152)
7.5 (109)
Servo Valve – bar (psi)
8.0 or 11.0 (116 or 160)
8.0 (116)
Vent Down Run Time @ 7 bar – sec
60
Vent Down Run Time @ 10 bar – sec
90
Pressure Display Units
0 (bar) (1 = psi, 2 = kpa)
Temperature Display Units
0 = °C (1 = °F)
Vacuum Relief Valve
1.5 turns anti-clockwise
INSTALLATION
Dimensions D x W x H –mm
685 x 630 x 1078
Weights - kg
220
230
Air Outlet Size - Rp
3/4
Minimum Room Volume - m
3
15
Air Inlet/Outlet Area - m
2
0.3
Ventilation Rate - m
3
/h
2000
Cooling Air Flow m
3
/h (cfm)
1850 (1089)
Recommended Air Receiver Capacity - litres
250
COMPRESSOR OIL
Approved compressor oil
Fluid Force Red 2000 (Mineral) and HPO (Synthetic)
Oil Capacity – litres
3
ELECTRICAL
Starter reference 200/575V 3PH 60Hz DOL
CC1118983
Circuit diagram 200/575V 3PH 60Hz DOL
CZ77996
Starter reference 400V 3PH 50Hz SD
CC1054889
Circuit diagram 400V 3PH 50Hz SD
CZ77989
Starter reference 400/460 3PH 50/60Hz RS
CC1054890
Circuit diagram 400/460V 3PH 50/60Hz RS
CZ77990
*Alternative speed settings may be required depending on application and duty cycle
