Hydrow WAVE - Specifications

hydrow.com | 54 | Hydrow Wave User Guide | 01/2023
Specification Measurement
Dimensions L x W x H: 80” x 19” x 43” (204 cm x 49 cm x 110 cm)
Dimensions with upright
storage system*
L x W x H: 26.5” x 30” x 82” (67 cm x 76 cm x 209 cm)
*Always use the upright storage system to stabilize the Hydrow Wave for vertical storage.
Hydrow Wave weight 102 lbs (46.3 kg); 128 lbs (58.2 kg) boxed
Height limit Fits up to a 36” inseam (91 cm)
Weight limit Holds up to 375 lbs (170 kg)
Connectivity Bluetooth 5.0 and ANT+, Wi-Fi 802.11 a/b/g/n/ac, Ethernet RJ45 (100 mbps)
Drag mechanism Dynamic and responsive computer-controlled resistance
Electrical 100-240 VAC, 50-60 Hz, Power (Peak): 190 W, Power (Avg): 27 W, Power (Idle): 1.1 W
Footrest adjustment Adjustable for correct foot placement
Handle Ergonomic design for low-stress grip
Handle strap High quality polyester webbing for super smooth and quiet operation
Materials Plastic frame with aluminum feet and monitor arm
Seat
Ergonomically designed cushion with a 2-roller and 2-idler system for smooth operation and
easy maintenance
Speakers Amplifier x2 channel, 3 W, 8 ohms, front facing for immersive experience
Touchscreen resolution 1920 x 1080 pixels Full HD
Touchscreen size 16” (41 cm)
Touchscreen technology Capacitive Touch Panel (CTP)
Usage class Class SA per EN ISO 20957-1 and 20957-7 for high accuracy and commercial use
Hydrow Wave qualifies as commercial grade, highly accurate fitness equipment per ISO 20957-1 and ISO 20957-7 and is rated class SA. Accuracy was determined
by connecting Hydrow Wave to a load cell that verified that Hydrow Wave’s reported watts were within the tolerance of the Class A criteria. Accuracy was character-
ized at a 104 drag setting with a 1.4 m stroke length.
Specifications
rear foot
front foot
flywheel
track
end cap
seat
footrests
monitor
touchscreen
monitor arm
handle
handle rest
handle strap
