Hypertherm Powermax 1000 User Manual

 DO NOT:
 Put hands on the gantry rails. You will lose fingers!
 Cut these materials due to TOXIC fumes :
 Anything cleaned with chlorinated cleaner (e.g. brake cleaner)
–PHOSGENE gas is generated
 Galvanized steel – causes “galvanize poisoning”
 Heavily painted material – causes arc degradation and
unpleasant if not dangerous offgassing
 Watch the arc without proper safety gear – AWS recommends
shade 8 or greater eyewear
 Handle material without proper PPE/Tools – hot material after
cutting will BURN
 Abuse the equipment (e.g. misusing the torch by placing the cutting
head over your hand & pulling the trigger)
Safety First!!!

Hypertherm Powermax 1000 Specifications

General

Open Circuit Voltage (OCV)	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Cut Capacity (Maximum)	1 in (25 mm)
Pierce Capacity	1/2" (13 mm) on mild steel
Gas Type	Air or Nitrogen
