230V CE INSTALLATION
230V CE Installation Manual
2-5
Figure 2-3 Wheels and Casters Installed on 230V Transformer Case
Figure 2-2 Wheel and Caster Installation
027249
Retaining
ring
008973
Shoulder
washer
027299
Caster
075470
10-32 screws (8)
004672
Axle
075174
10-32 star washers (8)
027057
Wheel
027057
Wheel
