230V CE INSTALLATION
2-4
230V CE Installation Manual
INSTALLATION OF WHEELS AND CASTERS TO TRANSFORMER
CASE
Wheel Installation
1. Carefully turn transformer case assembly upside down.
2. Snap an 027249 retaining ring on one end of the 004672 wheel axle.
3. Slide one 027057 wheel on the axle.
4. Slide 008973 shoulder washer over the end of the axle with the larger diameter end of
the washer facing the mounted wheel.
5. Slide the axle through both holes in the rear of the transformer case assembly.
6. Slide the second 008973 shoulder washer over the end of the axle with the smaller
diameter end of the washer facing the transformer case.
7. Slide the second 027057 wheel onto the axle.
8. Snap the second 027249 retaining ring on the end of the axle to secure the second
wheel.
Caster Installation
1. Attach the 027299 casters to the case with the 075470 10-32 screws and 075174 star
washers as shown in Figure 2-2.
2. Turn transformer case back over on to wheels - Figure 2-3.
Wheel and caster installation complete.
