8 Powermax45/45 XP Field Service Bulletin 807990
Powermax45/45 XP Snubber Resistor Replacement Kit
Figure 6 – Powermax45 snubber resistors
Snubber resistor – 10Ω
(Kit 428065)
Mounting screws*
* Torque all snubber resistor mounting screws to 23.0 kg cm (20 inch-pounds).
Heat sink
