9 HMS-600W / 800W USER MANUAL
4. UNPACKING
3.1 Product Overview
The total size of HMS- 600W / 800W is 230(width) ×190(height) ×46.5(depth) mm. It
has 2 pairs of PV input terminals.
The detail description is shown below:
Note: None of the accessories above is included in the package and should be purchased
separately.
Mark Num. Description
1 MC4 Disassembly tool
2 AC male connector end cap
3 AC female connector end cap
4 DC Extension Cable
5 M8 screws(prepared by the installer-self)
6 AC Extension Cable
Model Maximum units per branch
HMS-600W 7
HMS-800W 5
