4
Before Use
1
2
2. Attaching the Earpiece
1. Open the connector cover as
①
shown.
2. Align the index of the earpiece with that of the radio and connect
the earpiece to the radio as
②
shown.
3. Turn the earpiece clockwise as
③
shown to fasten it.
3. Attaching the Belt Clip
To attach the belt clip, perform the following steps.
“ click ”
After the belt clip is assembled to the radio, you can
wear the radio to a certain fixture (such as a belt).
The belt clip is designed with a buckle to ensure the
fixing performance. To take out the belt clip, press and
hold the buckle in the direction as arrow ① shows and
lift up the belt clip in the direction as arrow ② shows.
See the figure above.
Note
Attaching the Earpiece Attaching the Belt Clip
