Hytera DMR System Planner
76
Function Type Applicable
Mode
Definition
Carrier Detect Programmable Analog Upon receiving the call request from an
analog portable radio, the repeater will
output a valid level if the carrier
matches; when the portable radio stops
the call, the repeater will output an
invalid level for there is no carrier input.
Note: not applicable to users with
CTCSS/CDCSS enabled. The level can
indicate that whether the repeater is
working.
CTCSS/CDC
SS Detect
Programmable Analog Upon receiving the call request from an
analog portable radio, the repeater will
output a valid level if the
CTCSS/CDCSS signaling matches;
when the portable radio stops the call,
the repeater will output an invalid level
for there is no CTCSS/CDCSS signaling
input.
Note: applicable to users with
CTCSS/CDCSS enabled. The level can
indicate that whether the repeater is
working.
Rx Audio
Output
A fixed function Analog During its working, the repeater will
retransmit the received audio signals via
the accessory pin.
Voice Detect Programmable Digital When receiving the call request from a
digital portable radio, the repeater will
output a valid level if the signaling
matches; when the portable radio stops
the call, the repeater will output an
invalid level for there is no signaling
input.
The level can indicate that whether the
repeater is working.
Audio
Playback
Slot-A/Audio
Playback
Slot-B
A fixed function Digital During its working, the repeater will
retransmit the received audio signals via
the accessory pin.
You can select and monitor the time slot
output.
