Hytera PD78XG System Planner

Hytera DMR System Planner
82
2.11.3 Radio Control Service
（
RCP
）
Hytera provides radio control protocol specification and API library based on PC to
achieve radio system calling. Hytera digital radio is able to individual calling, group
calling and all calling. You can integrate all these calling into user system by ADK
and achieve calling from user’s application system.
Figure 2.11.3-1: Radio Control Protocol Architecture
Notes:
z In repeater API, HRNP is not needed, because HRNP is usually used in wired
communication, such as USB or UART.
As the chart shows, HRNP is a network layer protocol between PC application
system and the Dispatcher Station, and a user-defined protocol based on UDP/IP
through which PC application system transfers calling order to corresponding distant
radio by using the Dispatcher Station as a transient station. The Dispatcher Station
will transfer received calling request information to PC application system.
For more details, please refer to below files:
 Hytera DMR Application Protocol Specification
 Hytera DMR Application Programming Interface
 Hytera DMR ADK Development Guide
