Radio Overview
(1) PTT (Push-to-Talk) Key (2) SK (Side Key)
(3)Speaker (4) Volume Adjust Keys [+] / [-]
(5) Microphone (6) Nameplate
(7) Charging Terminal (8) Antenna
(9) Power Switch (10) Channel/Status Indicator
(11) Channel Selector Knob (12) Charge Indicator
(13) Accessory Jack Cover (14) Audio Accessory Jack
(15) Mini USB Jack (16) Strap Hole
(17) Screw (Belt Clip) (18) Belt Clip
(19) Rear Cover (20) Battery Latch
