Hytera TC-508 Service Manual

TC-508 Service Manual
23
TC-508 Parts List 1
TC-508 (400-420MHz)
No. Part No. Description Qty. Ref No. Print No.
1 3001050000000 Chip resistor 0Ω J 1/16W 0402 (RoHS) 1 R222 B5I
2 3001050000000 Chip resistor 0Ω J 1/16W 0402 (RoHS) 1 R442 B3E
3 3001050000000 Chip resistor 0Ω J 1/16W 0402 (RoHS) 1 R511 T3E
4 3001050000000 Chip resistor 0Ω J 1/16W 0402 (RoHS) 1 R533 T2G
5 3001050000000 Chip resistor 0Ω J 1/16W 0402 (RoHS) 1 R402 T4F
6 3001051000020 Chip resistor 10Ω F 1/16W 0402 (RoHS) 1 R108 T4I
7 3001051000020 Chip resistor 10Ω F 1/16W 0402 (RoHS) 1 R111 T5I
8 3001051000020 Chip resistor 10Ω F 1/16W 0402 (RoHS) 1 R315 B1A
9 3001051000020 Chip resistor 10Ω F 1/16W 0402 (RoHS) 1 R323 B1F
10 3001051000020 Chip resistor 10Ω F 1/16W 0402 (RoHS) 1 R408 T5F
11 3001051000020 Chip resistor 10Ω F 1/16W 0402 (RoHS) 1 R530 T2J
12 3001051000020 Chip resistor 10Ω F 1/16W 0402 (RoHS) 1 R531 T3I
13 3001051000020 Chip resistor 10Ω F 1/16W 0402 (RoHS) 1 R534 T3J
14 3001051010000 Chip resistor 100Ω J 1/16W 0402 (RoHS) 1 R101 T5I
15 3001051010000 Chip resistor 100Ω J 1/16W 0402 (RoHS) 1 R119 T4F
16 3001051010000 Chip resistor 100Ω J 1/16W 0402 (RoHS) 1 R123 T3G
17 3001051010000 Chip resistor 100Ω J 1/16W 0402 (RoHS) 1 R429 T3G
18 3001051010000 Chip resistor 100Ω J 1/16W 0402 (RoHS) 1 R604 B4I
19 3001051010000 Chip resistor 100Ω J 1/16W 0402 (RoHS) 1 R605 B4A
20 3001051010000 Chip resistor 100Ω J 1/16W 0402 (RoHS) 1 R614 B1C
21 3001051010000 Chip resistor 100Ω J 1/16W 0402 (RoHS) 1 R623 B2I
22 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R109 T4H
23 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R114 T4G
24 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R121 T4I
25 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R211 T1E
26 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R214 B2H
27 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R313 B3D
28 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R319 T1I
29 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R322 B2E
30 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R327 T1I
31 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R609 T2D
32 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R621 B2B
33 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R626 T2D
34 3001051020000 Chip resistor 1K
Ω F 1/16W 0402 (RoHS) 1 R644 T3I
35 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R650 B1H
36 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R683 T1D
37 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R684 T4H
38 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R690 B4J
39 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R691 B4J
40 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R692 B3J
41 3001051020000 Chip resistor 1KΩ F 1/16W 0402 (RoHS) 1 R693 B3J
