Hytera TC-508 Service Manual

TC-508 Service Manual
65
TC-508 Parts List 2
No. Part No Description
Qty
(PCS).
1 6001139000000 Front case 1
2 6100312000010 Silicone rubber PTT key 1
3 6000842100010 Plastic PTT key 1
4 7101904020200 Self-tapping screw ST1.94.0mm 10
5 PCB main board 1
6 6100542100000 Waterproof ring for radio 1
7 6300115000000 Aluminum chassis 1
8 7102508000010 Machine screw M2.58.0mm 1
9 41005002004B0 PTT Key PCB 1
10 7300032000000
Metal dome for PTT key
1
11 7102504000300 Machine screw M2.54.0mm 2
12 1602L13000000
Li-Ion battery pack
1
13 1605040000000 Belt Clip Kit With Metal Bracket 1
14 7103006004000 Machine screw M3.06.0mm 2
15 6001140000000
Rear cover
1
16 4400100008000
SMA RF connector
1
17 6100335000000 Antenna O-Ring 1
18 6100370000000 O-ring washer for the switch 2
19 4304030000010 Gray code rotary switch 1
20 4302020000140 Volume switch 1
21 6100314000000
Waterproof ring for battery connector
1
22 6000852000000 Bracket for earpiece jack 1
23 16010415W0050 Antenna 1
24 6000845100010 Channel selector knob 1
25 6000846100000 Volume control knob 1
26 6201739000000
Inner lining for knob
1
27 6201066000000
Inner lining for knob
1
28 7207002200200 Nut 2
29 6000854000000
Light guide
1
30 6201870000000 Speaker fixing sheet 1
31 5001210000470 Speaker 1
32 6100077000000 Speaker washer 1
33 7400322000000 Speaker felt 1
34 6000749000000 Accessory jack cover 1
35 5002220000070 Microphone 1
36 6100345000000 Mic cover 1
37 7400141000000
MIC mesh
1
Note: Parts that are not marked with material number may vary with radio frequency band.
