Hytera TC-508 Service Manual

TC-508 Service Manual
26
No. Part No. Description Qty. Ref No. Print No.
130 3001054730000 Chip resistor 47KΩ J 1/16W 0402 (RoHS) 1 R312 B3D
131 3001054730000 Chip resistor 47KΩ J 1/16W 0402 (RoHS) 1 R320 B1F
132 3001054730000 Chip resistor 47KΩ J 1/16W 0402 (RoHS) 1 R417 T5E
133 3001054730000 Chip resistor 47KΩ J 1/16W 0402 (RoHS) 1 R553 B1D
134 3001054730000 Chip resistor 47KΩ J 1/16W 0402 (RoHS) 1 R610 B3J
135 3001054730000 Chip resistor 47KΩ J 1/16W 0402 (RoHS) 1 R611 B3J
136 3001054730000 Chip resistor 47KΩ J 1/16W 0402 (RoHS) 1 R612 B3J
137 3001054730000 Chip resistor 47KΩ J 1/16W 0402 (RoHS) 1 R613 T2D
138 3001054730000 Chip resistor 47KΩ J 1/16W 0402 (RoHS) 1 R620 B3J
139 3001054730000 Chip resistor 47KΩ J 1/16W 0402 (RoHS) 1 R624 B2I
140 3001054730000 Chip resistor 47KΩ J 1/16W 0402 (RoHS) 1 C546 T3I
141 3001054740000 Chip resistor 470KΩ J 1/16W 0402 (RoHS) 1 R548 T4J
142 3001054740000 Chip resistor 470KΩ J 1/16W 0402 (RoHS) 1 R549 T4J
143 3001054790000 Chip resistor 4.7Ω J 1/16W 0402 (RoHS) 1 R318 B2D
144 3001055610000 Chip resistor 560Ω J 1/16W 0402 (RoHS) 1 R118 T4H
145 3001055630000 Chip resistor 56KΩ J 1/16W 0402 (RoHS) 1 R411 T5E
146 3001055630000 Chip resistor 56KΩ J 1/16W 0402 (RoHS) 1 R615 T1D
147 3001056810000 Chip resistor 680Ω J 1/16W 0402 (RoHS) 1 R646 B1G
148 3001056830000 Chip resistor 68KΩ J 1/16W 0402 (RoHS) 1 R102 T5I
149 3001056830000 Chip resistor 68KΩ J 1/16W 0402 (RoHS) 1 R124 T3G
150 3001058220000 Chip resistor 8.2KΩ J 1/16W 0402 (RoHS) 1 R407 B4E
151 3001058220000 Chip resistor 8.2KΩ J 1/16W 0402 (RoHS) 1 R514 T3E
152 3001058220000 Chip resistor 8.2KΩ J 1/16W 0402 (RoHS) 1 R607 B5I
153 3001058230000 Chip resistor 82KΩ J 1/16W 0402 (RoHS) 1 R524 T3J
154 3001060000000 Chip resistor 0Ω J 1/10W 0603 (RoHS) 1 L403 T5E
155 3001062710000 Chip resistor 270Ω J 1/10W 0603 (RoHS) 1 R418 B4B
156 3001062710000 Chip resistor 270Ω J 1/10W 0603 (RoHS) 1 R444 B4B
157 3001061540010 Chip resistor 150KΩ D 1/10W 0603 (RoHS) 1 R422 B4F
158 3001061540010 Chip resistor 150KΩ D 1/10W 0603 (RoHS) 1 R423 B4F
159 3001061540010 Chip resistor 150KΩ D 1/10W 0603 (RoHS) 1 R424 B4F
160 3001061540010 Chip resistor 150KΩ D 1/10W 0603 (RoHS) 1 R425 B4F
161 3001061540010 Chip resistor 150KΩ D 1/10W 0603 (RoHS) 1 R426 B4F
162 3001061540010 Chip resistor 150KΩ D 1/10W 0603 (RoHS) 1 R427 B4F
163 3001070000000 Chip resistor 0
Ω J 1/8W 0805 (RoHS) 1 R326 B1C
164 3002991030160 Adjustable resistor10K ±25% 0.15W 2.2*2.81*0 SMD (RoHS) 1 VR101 T4I
165 3005051020010 Integrated resistor 1K J 1/16W 4*0402 (RoHS) 1 RN101 T4J
166 3099080398000 Chip resistor 0.39Ω J 1/4W 1206 (RoHS) 1 R419 B3B
167 3099080398000 Chip resistor 0.39Ω J 1/4W 1206 (RoHS) 1 R420 B3B
168 3099080398000 Chip resistor 0.39Ω J 1/4W 1206 (RoHS) 1 R421 B4B
169 3101050200010 Chip capacitor 2PF B 50V C0G 0402 (RoHS) 1 C137 T3H
170 3101050200010 Chip capacitor 2PF B 50V C0G 0402 (RoHS) 1 C151 T3G
171 3101050200010 Chip capacitor 2PF B 50V C0G 0402 (RoHS) 1 C501 T4C
172 3101050200010 Chip capacitor 2PF B 50V C0G 0402 (RoHS) 1 C530 T2F
173 3101050400010 Chip capacitor 4PF B 50V COG 0402 (RoHS) 1 C502 T4C
