5. Press and hold the start button (C) on the remote control until the square drive no
longer turns.
The piston in the tool is in the fully extended position.
Note: If the piston does not move, turn the pressure control valve (B)
360° clockwise.
6. Release the start button (C) on the remote control.
The piston in the tool moves to the fully retracted position.
7. Repeat steps 4 through 6 three times.
8. Set the correct torque.
a) Press and hold the start button (C) on the remote control.
b) Turn the pressure control valve (B) until the pressure gauge shows the correct
pressure.
c) Release the start button (C) on the remote control.
d) After a few seconds, press and hold the start button (C) on the remote control to
check the pressure.
e) If the pressure is correct, tighten the wingnut on the pressure control valve (B) of
the pump unit.
f) After a few seconds, press and hold the start button (C) on the remote control to
check the pressure.
6.5 Replacing the ratchet link
Procedure
1. Remove the link pin (A).
2. Press the link release button (B)
and pull the power head (C) from
the ratchet link.
3. Place the power head (C) on the
replacing ratchet link.
4. Push the power head (C) until the
link release button (B) clicks.
5. Place the link pin (A).
