Note: If the area of the hex
drive is smaller than the ratch-
et link drive, HYTORC will dis-
claim any liability for broken
stacking nutheads and hex
drives. These male hex sock-
ets are excluded from warran-
ty claims:
• 1/2” x 17 mm (11/16") and
smaller
• 3/4” x 22 mm (7/8”) and
smaller
• 1” x 27 mm (1 1/8") and
smaller
• 1 1/2” x 46 mm (1 5/6”)
and smaller
• 2 1/2” x 70 mm (2 1/2”)
and smaller
Extra shear forces and bend-
ing forces caused by an im-
perfect reaction level and/or a
short reaction distance will
lower the specified values.
Technical data
42 37 - 001 -
