Important note:
Other anodized HYTORC swivels, for example MXT swivels, are NOT suited for explosion protection!
Example: Pink anodized STEALTH swivel Example: Blue anodized MXT swivel
Not suited for explosion protection! Not suited for explosion protection!
The HYTORC HY-AIR hydraulic pump is equipped as follows:
b) Equipped with metal feet.
3. Component: The HYTORC hydraulic torque wrench. The torque wrench must be equipped as follows:
a) Solid metal spring on each male and female coupling (between coupler and tting).
b) The joints of the swivel on the hydraulic wrench must not be ANODIZED!
Only the polished swivel can be used!

Hytorc Stealth series Specifications

General

Series	Stealth
Type	Hydraulic Torque Wrench
Power Source	Hydraulic
Weight	Varies by model
Operating Pressure (max)	10, 000 psi
Accuracy	+/- 3%
