Ref.
No.
Part No. Description
1
2
3
4
5
R-00145
R-00035
R-00150
R-00040
R-00147
Speed Reducer Housing - 4A & 4AC
Worm Gear (Specify Ratio)
Worm Shaft - V-Belt Drive (Specify Ratio)
Output Shaft
Front Cover
6
7
8
9
10
R-00148
R-00149
012.102
012.103
012.106
Side Cover
Side Cover (Input) V-Belt Drive Only
Bearing Cone - 1 in. I.D.
Bearing Cup - 1.9687 in. O.D.
Bearing Cone - .84375 in. I.D.
11
12
13
14
15
012.107
051.114
R-00154
015.1015
015.1025
Bearing Cup - 1.96875 in. O.D.
Spacer - 1 in I.D. x 1.25 in. O.D. x 1.215 in. Long
Reducer Splash Shield
Seal - Double Lip, 3/4 in Shaft x 1.375 in. Bore
Seal - Double Lip, 1 in Shaft x 1.625 in. Bore
16
---
---
---
---
---
052.118
052.1181
052.1182
052.1183
Gasket - Front Cover
.004 in Thick
.010 in Thick
.016 in Thick
.031 in Thick
• Model 4A and 4AC Parts Drawing & List
Dibujo y Lista de Partes del Modelo 4A y 4AC
*For models shipped prior to April 2005, please contact factory.
*Para modelos embarcados antes de abril de 2005, por favor
contáctenos
24
21
21
11
7
20
3
18
14
17
20
6
17
11
1
21
18
8
22
12
13
8
4
16
18
5
14
20
20
17
25
18
9
9
2
15
26
10
10
24
21
21
11
7
20
3
18
14
17
20
6
17
11
1
21
18
8
22
12
13
8
4
16
18
5
14
20
20
17
25
18
9
9
2
15
26
10
10
Important!
Manufacturing advancements necessitates changes in parts.
Always contact the Integration Partner when replacement parts are
needed. Some replacement parts may effect other parts required.
Please have the conveyor serial number when ordering.
¡Importante!
Los avances en fabricación demandan cambios de partes.
Contacte siempre al Integrador cuando necesite refaccionamiento.
Algunas refacciones pueden afectar las otras partes requeridas. Por
favor tenga el número de serie del transportador cuando realice sus
órdenes.
17
18
19
20
21
052.1192
---
095.100
049.539
092.0372
Gasket - Side Cover - .016 in Thick
Gasket Sealing Paste (Not Shown, Available locally)
Gear Reducer Oil (Not Shown)
5/16-18 x 3/4 in. Lg Flange Lockbolt
3/8 in NPT Steel Pipe Plug w/C’sunk Hex
22
23
24*
25*
26*
090.201
R-00122
R-00151
R-00146
---
Shaft Key - #807 Woodruff
Vent Plug Kit (Not Shown)
Worm Shaft - C-Face Drive (Specify Ratio)
C-Face Motor Adapter - 56,143/145T Frames
Flexible Coupling Kit - Motor to Reducer
---
---
27
28
29
B-09179-B
B-09179-C
R-00152
R-00153
R-00157
5/8 in. to 3/4 in. (1/2 thru 1 HP)
3/4 in. to 7/8 in. (2 HP)
4A Reducer - Complete (Specify Ratio and Hand)
4AC Reducer - Complete (Specify Ratio and Hand)
4A Reducer - Complete, Timing Belt Drive
(Specify Ratio and Hand)
30
31
32
R-00158
R-00155
R-00156
4AC Reducer - Complete. Timing Belt Drive
(Specify Ratio and Hand)
4A Reducer - Complete Double Sprocket Drive
(Specify Ratio and Hand)
4A Reducer - 6:1 Variable Speed Drive (Specify Hand)
* FOR 4AC REDUCER ONLY
