7-6
2. STARTING CIRCUIT
OPERATING FLOW
Battery(+) terminal Start motor[CN-45(B+)] Fusible link[CN-95A]
Alternator[CN-74(B+)] I/conn[CN-1] Start switch[CS-2(3)]
Start relay[CR-23(87)]
Glow relay[CR-24(30)]
※The engine can be started only when the gearshift is in neutral position.
When start key switch is in ON position
When start key switch is in ON position
Start switch ON [CS-2(4)] Fuse box[No. 5→7] [CN-1(19)] Fuel stop solenoid[CN-87(1)]
Fuse box[No. 5→8] Glow relay[CR-24(85→87)] I/conn[CN-1]
Fusible link[CN-95B] Glow plug[CN-80]
When start key switch is START position
When start key switch is START position
Start switch START[CS-2(2)]
Fuse box[CN-36(4)] Neutral relay[CR-5(4
→
2)] Safety relay[CR-23(86
→
30)]
I/conn[CN-1] Starter
1)
(1)
(2)
CHECK POINT
2)
Engine Key switch Check point Voltage
Running ON
①
- GND (Battery B+)
②
- GND (Fusible link)
③
- GND (Fuse box)
④
- GND (Start key)
⑤
- GND (Starter relay)
10 ~ 14.5
V
