1-11
FITTING
FITTING
4)
4)
PIPE AND HOSE
PIPE AND HOSE (FLARE type)
2)
2)
PIPE AND HOSE
PIPE AND HOSE (ORFS type)
3)
3)
Thread size Width across flat ( mm ) kgf·m lbf·ft
1/4" 19 4 28.9
3/8" 22 5 36.2
1/2" 27 9.5 68.7
3/4" 36 18 130
1" 41 21 152
1-1/4" 50 35 253
Thread size Width across flat ( mm ) kgf·m lbf·ft
9/16-18 19 4 28.9
11/16-16 22 5 36.2
13/16-16 27 9.5 68.7
1-3/16-12 36 18 130
1-7/16-12 41 21 152
1-11/16-12 50 35 253
Thread size Width across flat ( mm ) kgf·m lbf·ft
1/4" 19 4 28.9
3/8" 22 5 36.2
1/2" 27 9.5 68.7
3/4" 36 18 130
1" 41 21 152
1-1/4" 50 35 253
