Owner's Guide: SS5 Stepper Servo Motor Driver
Page 4
TECHNICAL DOCUMENT
3. Specification
Parameters
Min
Typical
MAX
Unit
Supply voltage
24
-
75
VDC
Output current（Peak）
1.0
-
9.8
A
Control signal input current
6
10
15
mA
STEP/DIR Input Signal Voltage
4.0
5.0
28.0
VDC
Step Frequency
2
-
1M
Hz
STEP Minimum Pulse Width High and
Low
250
-
-
Ns
DIR Minimum Pulse Width
50
-
-
us
Drive initialization time
-
-
2
S

I.CH Motion SS5 Specifications

General

Brand	I.CH Motion
Model	SS5
Category	Control Unit
Language	English
