I-GARD DSP-OHMNI Instruction Manual
28
TABLE 13.5 FEEDER MODULE GROUND CURRENT ADDRESSES
Register No Contents Format Register No. Contents Format
40001 Feeder 1 Igf 0x00nn 40026 Feeder 26 Igf 0x00nn
40002 Feeder 2 Igf 40027 Feeder 27 Igf
40003 Feeder 3 Igf 40028 Feeder 28 Igf
40004 Feeder 4 Igf 40029 Feeder 29 Igf
40005 Feeder 5 Igf 40030 Feeder 30 Igf
40006 Feeder 6 Igf 40031 Feeder 31 Igf
40007 Feeder 7 Igf 40032 Feeder 32 Igf
40008 Feeder 8 Igf 40033 Feeder 33 Igf
40009 Feeder 9 Igf 40034 Feeder 34 Igf
40010 Feeder 10 Igf 40035 Feeder 35 Igf
40011 Feeder 11 Igf 40036 Feeder 36 Igf
40012 Feeder 12 Igf 40037 Feeder 37 Igf
40013 Feeder 13 Igf 40038 Feeder 38 Igf
40014 Feeder 14 Igf 40039 Feeder 39 Igf
40015 Feeder 15 Igf 40040 Feeder 40 Igf
40016 Feeder 16 Igf 40041 Feeder 41 Igf
40017 Feeder 17 Igf 40042 Feeder 42 Igf
40018 Feeder 18 Igf 40043 Feeder 43 Igf
40019 Feeder 19 Igf 40044 Feeder 44 Igf
40020 Feeder 20 Igf 40045 Feeder 45 Igf
40021 Feeder 21 Igf 40046 Feeder 46 Igf
40022 Feeder 22 Igf 40047 Feeder 47 Igf
40023 Feeder 23 Igf 40048 Feeder 48 Igf
40024 Feeder 24 Igf 40049 Feeder 49 Igf
40025 Feeder 25 Igf 40050 Feeder 50 Igf
Feeder Module Status is represented by fi ve valid states as follows:
0x00 = OK
0x01 = Faulted feeder
0x02 = Feeder Tripped
0x03 = Test Button pushed
0x0f = Not available
The registers following return two bytes – The fi rst byte is always 0x00 with the second returning
status in hexadecimal as above.
