I-GARD DSP-OHMNI Instruction Manual

J3 RS-485

Communications

20 Conductor

Cable to DSP-DPS

To Next Device, or

Converter

Figure 15.6 DSP-DM Display Module Connections

16 ADDITIONAL INFORMATION

If you require more information or experience problems with your equipment that persist after taking the steps

identiﬁed in this manual, please contact I-Gard Customer Service.
