BB7 Beamlight tech spec
Dimensions
Length 617 mm overall height from yoke top to point at base
Depth 217 mm overall depth
Width 516 mm overall width with standard yoke fitted
Weight 19Kg total
Mechanical design/ materials used
Batten Aluminium shrouded finned diagonal heatsink
Yoke Folded high grade aluminium
Finish Electro static powder coated black satin
Rigging
Style 4 ¼ turn camloc fasteners which yoke/ rigging options attach to
Accessory holder Slot for future optical accessories pre-fitted with double camloc retainer
Conventional mounts 1 of 12mm bolt holes fitted at each yoke end
Electrical connections for mains and data in/out
Combined power and data connection
Input Trailing male IP67 6 pin
Output Chassis mounted female IP67 6 pin
Electrical
210 watts total power on full.
Input 90- 265 Volt 50/60 Hz
Power 0.9 amps @ 240 volts
Fuse 20mm x 5mm slow blow 8 amp
Output to fixture 15 volts max
Data type USITT DMX512-A
Note; units comes complete with 16 amp cee form plug and 5 pin xlr both male..
Control RGB additive colour mixing
DMX channels 3 channels minimum 63 channels maximum
User interface Weatherproof backlit lcd display with four membrane switches
Modes 8 bit standard resolution:
1 1 x RGB over 7 cells
3 1 x RGB over 7 cells with an overall master and strobe
5 7 x RGB
7 7 x RGB with an overall master and strobe
9 7 x RGB each with individual master and strobe
16 bit high resolution (recommended)
2 1 x RGB over 7 cells
4 1 x RGB over 7 cells with an overall master and strobe
6 7 x RGB
8 7 x RGB with an overall master and strobe
10 7 X RGB each with individual master and strobe
note 16 bit for every channel bar strobe which runs as 8 bit
BB7 USERS MANUAL - PAGE 20
