fig 1
fig 2
RIGGING
BB7 USERS MANUAL - PAGE 6
The BB7 is a very simple light to rig all that is necessary is to bolt your clamp of choice to the yoke obviously
selecting one that is well capable of taking the weight of the light and then using at least one safety bond
attached to one of the 2 safety points.
ALWAYS secure the lamp to the truss, pipe e.t.c. with a safety bond. The BB7 has 2 safety points to which a bond
can be attached. One eye bolt is at the top of the lamp near the user interface shown in fig 1 the other is at the
bottom of the lamp next to the input cable shown in fig 2.
