Light Engine
Source Customised lamina Titan RGB LED
Wavelengths Red 625 Nm +/- 2.5 Nm
Green 517 Nm +/- 2.5 Nm
Blue 452.5 Nm +/- 2.5 Nm
Optics 7 x 10 degree optic
Thermal characteristics
Fixture rear Passive convection cooled
Fixture front Force air cooled via low airflow/ low noise fans, mounted within the chassis
Operating Minimum: -20 degrees C
temperature Maximum:+ 46 degrees C
Weather protection
Fixture This fixture will work outside with optional weather proofing,
otherwise IP20
Humidity max 20% ~ 90% RH non-condensing
Approvals & Compliance
BS EN 55103-1 Harmonics
BS EN 55103-2 Immunity
BS EN 61000-3-2 Emissions
USA / Canada ETL pending
Lead and mercury free return to manufacturer for recycling
IP Protection Patents filed in USA
Manufactured in the United Kingdom by
We reserve the right to improve this fixtures design.
BB7 USERS MANUAL - PAGE 21
